Alibaba Cloud DashScope Paraformer Real-Time Speech Recognition Integration Guide

目录

Preface

With the rapid development of AI technology, speech recognition has become a standard feature in many applications. Alibaba Cloud’s DashScope platform provides a powerful Paraformer real-time speech recognition service that supports streaming input and returns recognition results in real time. This article explains in detail how to integrate this service into a web application.

Technical Architecture

┌─────────────┐      WebSocket      ┌──────────────┐      WebSocket      ┌─────────────┐
│   浏览器    │ ◄─────────────────► │  FastAPI     │ ◄─────────────────► │  DashScope  │
│  (WebRTC)   │    音频数据/结果    │   后端服务    │    音频数据/结果    │  Paraformer │
└─────────────┘                     └──────────────┘                     └─────────────┘

Preparation

1. Get an Alibaba Cloud API Key

1. Visit the Alibaba Cloud DashScope console
2. Create an API Key
3. Note down the Key value; it will be used in the code later

2. Install dependencies

pip install dashscope fastapi uvicorn websockets

Backend Implementation (FastAPI)

Core code

"""
Paraformer 实时语音识别服务
使用阿里云 DashScope Python SDK
"""

import os
import json
import asyncio
import threading
import queue
import logging
import time
from fastapi import APIRouter, WebSocket, WebSocketDisconnect

logger = logging.getLogger(__name__)
router = APIRouter()

# 配置 API Key
DASHSCOPE_API_KEY = os.getenv("DASHSCOPE_API_KEY", "")
if DASHSCOPE_API_KEY:
    import dashscope
    dashscope.api_key = DASHSCOPE_API_KEY


class ASRClient:
    """封装 ASR 客户端，处理缓冲和识别"""

    def __init__(self, client_id: str):
        self.client_id = client_id
        self.audio_buffer = bytearray()
        self.result_queue = queue.Queue()
        self.recognition = None
        self.recognition_thread = None
        self.final_text = ""
        self.complete_event = threading.Event()

    def start_recognition(self):
        """启动语音识别"""
        from dashscope.audio.asr import (
            Recognition, RecognitionCallback, RecognitionResult
        )

        class Callback(RecognitionCallback):
            def __init__(self, client):
                self.client = client

            def on_open(self):
                logger.info(f"[CLIENT {self.client.client_id}] DashScope 连接打开")

            def on_close(self):
                logger.info(f"[CLIENT {self.client.client_id}] DashScope 连接关闭")

            def on_complete(self):
                logger.info(f"[CLIENT {self.client.client_id}] 识别完成")
                self.client.result_queue.put({"type": "complete"})
                self.client.complete_event.set()

            def on_error(self, result: RecognitionResult):
                msg = result.message if hasattr(result, 'message') else str(result)
                logger.error(f"[CLIENT {self.client.client_id}] 识别错误: {msg}")
                self.client.result_queue.put({"type": "error", "error": msg})
                self.client.complete_event.set()

            def on_event(self, result: RecognitionResult):
                try:
                    sentence = result.get_sentence()
                    if sentence and isinstance(sentence, dict):
                        text = sentence.get("text", "")
                        is_final = RecognitionResult.is_sentence_end(sentence)

                        if text:
                            logger.info(f"识别: '{text}' (final={is_final})")
                            if is_final:
                                self.client.final_text += text
                                self.client.result_queue.put({
                                    "type": "final", "text": text
                                })
                            else:
                                self.client.result_queue.put({
                                    "type": "partial",
                                    "text": self.client.final_text + text
                                })
                except Exception as e:
                    logger.error(f"处理事件错误: {e}")

        callback = Callback(self)
        self.recognition = Recognition(
            model='paraformer-realtime-8k-v2',
            format='pcm',
            sample_rate=8000,
            callback=callback
        )

        def run():
            try:
                # 先发送缓冲区中的数据
                if self.audio_buffer:
                    self.recognition.send_audio_frame(bytes(self.audio_buffer))
                    self.audio_buffer.clear()

                # 启动识别（阻塞直到完成）
                self.recognition.start()
            except Exception as e:
                logger.error(f"识别线程错误: {e}")
                self.result_queue.put({"type": "error", "error": str(e)})
                self.complete_event.set()

        self.recognition_thread = threading.Thread(target=run, daemon=True)
        self.recognition_thread.start()

    def add_audio(self, audio_data: bytes):
        """添加音频数据"""
        try:
            if (self.recognition and
                hasattr(self.recognition, '_running') and
                self.recognition._running):
                self.recognition.send_audio_frame(audio_data)
            else:
                self.audio_buffer.extend(audio_data)
        except Exception as e:
            self.audio_buffer.extend(audio_data)

    def stop(self):
        """停止识别"""
        if self.recognition:
            try:
                self.recognition.stop()
            except:
                pass
        if self.recognition_thread:
            self.recognition_thread.join(timeout=2.0)


@router.websocket("/ws/voice")
async def voice_websocket(websocket: WebSocket):
    """WebSocket 实时语音识别"""
    await websocket.accept()

    if not DASHSCOPE_API_KEY:
        await websocket.send_json({
            "type": "error", "error": "未配置 DASHSCOPE_API_KEY"
        })
        await websocket.close()
        return

    client_id = str(id(websocket))
    client = ASRClient(client_id)
    recognition_started = False
    result_task = None

    try:
        await websocket.send_json({
            "type": "ready", "message": "请发送音频数据"
        })

        # 后台任务：实时发送识别结果给客户端
        async def send_results_realtime():
            """从 result_queue 获取识别结果并实时发送给客户端"""
            result_count = 0
            last_result_time = time.time()

            while True:
                try:
                    msg = client.result_queue.get_nowait()
                    result_count += 1
                    last_result_time = time.time()
                    await websocket.send_json(msg)

                    if msg.get("type") in ["complete", "error"]:
                        # 再等待2秒，确保没有遗漏的消息
                        await asyncio.sleep(2.0)
                        while True:
                            try:
                                msg = client.result_queue.get_nowait()
                                await websocket.send_json(msg)
                            except queue.Empty:
                                break
                        break

                except queue.Empty:
                    time_since_last = time.time() - last_result_time
                    if time_since_last > 30:
                        break
                    await asyncio.sleep(0.05)
                    continue

                except Exception as e:
                    logger.error(f"发送结果错误: {e}")
                    break

        # 接收音频数据
        while True:
            try:
                data = await asyncio.wait_for(websocket.receive(), timeout=0.5)

                if isinstance(data, dict):
                    msg_type = data.get('type')
                    if msg_type == 'websocket.receive':
                        # 控制消息
                        text_data = data.get('text')
                        if text_data:
                            try:
                                msg = json.loads(text_data)
                                if msg.get("type") == "start":
                                    if not recognition_started:
                                        client.start_recognition()
                                        recognition_started = True
                                        result_task = asyncio.create_task(
                                            send_results_realtime()
                                        )
                                        await websocket.send_json({
                                            "type": "status",
                                            "message": "recognition_started"
                                        })
                                elif msg.get("type") == "stop":
                                    break
                            except json.JSONDecodeError:
                                pass
                        # 音频数据
                        bytes_data = data.get('bytes')
                        if bytes_data:
                            client.add_audio(bytes_data)
                            if (not recognition_started and
                                len(client.audio_buffer) >= 16000):
                                client.start_recognition()
                                recognition_started = True
                                result_task = asyncio.create_task(
                                    send_results_realtime()
                                )
                                await websocket.send_json({
                                    "type": "status",
                                    "message": "recognition_started"
                                })
                    elif msg_type == 'websocket.disconnect':
                        break

            except asyncio.TimeoutError:
                continue
            except WebSocketDisconnect:
                break

        # 等待实时发送任务完成
        if result_task:
            try:
                await asyncio.wait_for(result_task, timeout=35.0)
            except asyncio.TimeoutError:
                result_task.cancel()

    except Exception as e:
        logger.error(f"语音识别错误: {e}")
    finally:
        if result_task:
            result_task.cancel()
        client.stop()
        try:
            await websocket.close()
        except:
            pass

Key points

1. RecognitionCallback: You must implement all callback methods (on_open, on_close, on_complete, on_error, on_event)
2. Audio format: Must be 8kHz sample rate, 16-bit PCM, mono
3. Buffering strategy: Buffer about 1 second of audio (16000 bytes) before starting the recognizer, to avoid NO_VALID_AUDIO_ERROR
4. Real-time push: Use queue.Queue and an asyncio background task to push results in real time

Frontend Implementation

// 语音录制状态
let isVoiceRecording = false;
let voiceWs = null;
let voiceAudioContext = null;
let voiceProcessor = null;
let voiceStream = null;
let voiceFinalText = '';
let voicePartialText = '';

async function toggleVoiceRecording() {
    if (!isVoiceRecording) {
        await startVoiceRecording();
    } else {
        await stopVoiceRecording();
    }
}

async function startVoiceRecording() {
    try {
        // 重置状态
        voiceFinalText = '';
        voicePartialText = '';

        // 获取麦克风权限 (8kHz 采样率)
        voiceStream = await navigator.mediaDevices.getUserMedia({
            audio: {
                sampleRate: 8000,      // 8kHz 与模型匹配
                channelCount: 1,       // 单声道
                echoCancellation: true,
                noiseSuppression: true
            }
        });

        // 连接 WebSocket
        const wsUrl = `ws://${window.location.host}/ws/voice`;
        voiceWs = new WebSocket(wsUrl);

        voiceWs.onopen = () => {
            console.log('语音识别 WebSocket 连接成功');
            startVoiceAudioProcessing();
        };

        voiceWs.onmessage = (event) => {
            const data = JSON.parse(event.data);
            handleVoiceMessage(data);
        };

        voiceWs.onerror = (error) => {
            console.error('WebSocket 错误:', error);
            stopVoiceRecording();
        };

        voiceWs.onclose = () => {
            console.log('WebSocket 关闭');
        };

        // 更新 UI
        isVoiceRecording = true;
        document.getElementById('voiceBtn').classList.add('recording');

    } catch (err) {
        console.error('启动录音失败:', err);
        showToast('无法访问麦克风: ' + err.message, 'error');
    }
}

function startVoiceAudioProcessing() {
    // 创建音频上下文
    voiceAudioContext = new (window.AudioContext || window.webkitAudioContext)({
        sampleRate: 8000
    });

    // 创建音频源
    const source = voiceAudioContext.createMediaStreamSource(voiceStream);

    // 创建处理器 (bufferSize=1024, 单声道)
    voiceProcessor = voiceAudioContext.createScriptProcessor(1024, 1, 1);

    voiceProcessor.onaudioprocess = (e) => {
        if (!isVoiceRecording || !voiceWs || voiceWs.readyState !== WebSocket.OPEN)
            return;

        // 获取音频数据
        const inputData = e.inputBuffer.getChannelData(0);

        // 转换为 16位 PCM
        const pcmData = floatTo16BitPCM(inputData);

        // 发送音频数据到服务器
        voiceWs.send(pcmData);
    };

    // 连接音频节点
    source.connect(voiceProcessor);
    voiceProcessor.connect(voiceAudioContext.destination);
}

function floatTo16BitPCM(float32Array) {
    const buffer = new ArrayBuffer(float32Array.length * 2);
    const view = new DataView(buffer);

    for (let i = 0; i < float32Array.length; i++) {
        let s = Math.max(-1, Math.min(1, float32Array[i]));
        s = s < 0 ? s * 0x8000 : s * 0x7FFF;
        view.setInt16(i * 2, s, true);
    }

    return buffer;
}

function handleVoiceMessage(data) {
    const input = document.getElementById('userInput');

    if (data.type === 'ready') {
        console.log('语音识别服务就绪');

    } else if (data.type === 'status') {
        console.log('语音识别状态:', data.message);

    } else if (data.type === 'partial') {
        // 中间结果 - 实时显示
        voicePartialText = data.text;
        input.value = voiceFinalText + voicePartialText;
        input.style.color = '#666';

    } else if (data.type === 'final') {
        // 最终结果片段
        voiceFinalText += data.text;
        voicePartialText = '';
        input.value = voiceFinalText;
        input.style.color = '';

    } else if (data.type === 'complete') {
        console.log('识别完成');

    } else if (data.type === 'error') {
        console.error('语音识别错误:', data.error);
        showToast('语音识别错误: ' + data.error, 'error');
    }
}

async function stopVoiceRecording() {
    if (!isVoiceRecording) return;

    isVoiceRecording = false;

    // 停止音频处理
    if (voiceProcessor) {
        voiceProcessor.disconnect();
        voiceProcessor = null;
    }

    if (voiceStream) {
        voiceStream.getTracks().forEach(track => track.stop());
        voiceStream = null;
    }

    if (voiceAudioContext) {
        voiceAudioContext.close();
        voiceAudioContext = null;
    }

    // 发送停止命令
    if (voiceWs && voiceWs.readyState === WebSocket.OPEN) {
        voiceWs.send(JSON.stringify({ type: 'stop' }));
        setTimeout(() => {
            voiceWs.close();
            voiceWs = null;
        }, 1000);
    }

    // 自动发送识别的消息
    const finalText = voiceFinalText + voicePartialText;
    if (finalText.trim()) {
        input.value = finalText.trim();
        setTimeout(() => {
            sendMessage();
        }, 300);
    }
}

Common Issues

1. NO_VALID_AUDIO_ERROR

Cause: The DashScope server did not receive valid audio data

Solution:

• Make sure the audio format is correct (8kHz, 16-bit PCM, mono)
• Buffer about 1 second of audio before starting the recognizer
• Check whether microphone permission was granted successfully

2. Recognition results are not returned in real time

Cause: recognition.start() is blocking, so a background task is needed to push results

Solution:

# 启动后台任务实时推送结果
result_task = asyncio.create_task(send_results_realtime())

3. WebSocket connection drops

Cause:

• No data sent for a long time
• Unstable network

Solution:

• Keep sending audio data continuously
• Implement a reconnection mechanism

Summary

Through this article, we have completed the integration of Alibaba Cloud DashScope Paraformer real-time speech recognition. The core points:

1. Audio format: 8kHz, 16-bit PCM, mono
2. Buffering strategy: Buffer 1 second of audio before starting recognition
3. Real-time push: Use queue + asyncio background task
4. Callback handling: Implement the complete RecognitionCallback

The full code has been open-sourced; feel free to refer to and use it.

Reference Links

• Alibaba Cloud DashScope documentation
• Paraformer real-time speech recognition
• GitHub sample code

---

Author: Awen
Published: 2026-04-03
Tags: #SpeechRecognition #AlibabaCloud #DashScope #Paraformer #WebSocket #FastAPI

文章作者：阿文

文章链接： https://www.awen.me/post/ffee1873.html

版权声明：本博客所有文章除特别声明外，均采用 CC BY-NC-SA 4.0 许可协议。转载请注明来自 阿文的博客！
