Tauri Cross-Platform Build Pitfall Guide: A Full Walkthrough from Biome to Rust Linking

目录

While developing ClipVault, a cross-platform clipboard manager, I went through the full gauntlet from code-style checks to multi-platform compilation. This article documents the complete solution set, from Biome CI check failures to Rust cross-platform linking errors.

Project Background

• Tech stack: Tauri 2.0 + React + Rust
• Target platforms: Windows (x86/x64/ARM64) + macOS (Intel/Apple Silicon) + Linux (x64/ARM64)
• CI/CD: GitHub Actions

---

Pitfall One: Biome CI Version Mismatch and Code Style

Symptom

GitHub Actions errors out when running biome ci .:

Notice: The configuration schema version does not match the CLI version 2.4.6
Expected: 2.4.6, Found: 2.2.6

Along with a pile of code-style errors:

• Error: The properties are not sorted. (CSS properties not sorted)
• Error: The object properties are not sorted by key. (object keys not sorted)
• Error: Provide an explicit type attribute for the button element. (button missing a type attribute)

Cause Analysis

1. Version mismatch: local Biome version (2.2.6) doesn’t match the CI environment (2.4.6)
2. Strict rules: Biome enables strict rules like useSortedProperties and useSortedKeys by default
3. dist directory: the build output directory was mistakenly included in the check scope

Solution

1. Unify the version

// biome.json
{
  "$schema": "https://biomejs.dev/schemas/2.4.6/schema.json"
}

# Upgrade local Biome
pnpm add -D @biomejs/biome@2.4.6

2. Exclude files that shouldn’t be checked

// biome.json
{
  "files": {
    "includes": ["**", "!package.json", "!.release-it.ts", "!dist/**", "!scripts/auto-fix.js"]
  }
}

3. Auto-fix code style

pnpm biome check --write --unsafe .

Key Config

{
  "$schema": "https://biomejs.dev/schemas/2.4.6/schema.json",
  "assist": {
    "actions": {
      "source": {
        "organizeImports": "on",
        "useSortedAttributes": "on",
        "useSortedKeys": "on",
        "useSortedProperties": "on"
      }
    }
  },
  "files": {
    "includes": ["**", "!package.json", "!.release-it.ts", "!dist/**"]
  }
}

---

Pitfall Two: Wrong Rust Cross-Platform Linker Configuration

Symptom

The Linux build errors out:

error: linking with `cc` failed: exit status: 1
rust-lld: error: cannot open /FORCE:MULTIPLE: No such file or directory
collect2: error: ld returned 1 exit status

Cause Analysis

/FORCE:MULTIPLE is a Windows MSVC linker-specific option used to forcibly allow multiple definitions. When that option is mistakenly passed to Linux’s ld linker, the build fails.

Wrong Configuration

# .cargo/config.toml ❌ wrong
[build]
rustflags = ["-C", "link-arg=/FORCE:MULTIPLE", "-C", "prefer-dynamic"]

Solution

Use Cargo’s conditional target configuration to apply the option only under the Windows target:

# .cargo/config.toml ✅ correct

# Windows targets need the /FORCE:MULTIPLE linker option
[target.x86_64-pc-windows-msvc]
rustflags = ["-C", "link-arg=/FORCE:MULTIPLE"]

[target.i686-pc-windows-msvc]
rustflags = ["-C", "link-arg=/FORCE:MULTIPLE"]

[target.aarch64-pc-windows-msvc]
rustflags = ["-C", "link-arg=/FORCE:MULTIPLE"]

# Linux ARM target configuration
[target.aarch64-unknown-linux-gnu]
linker = "aarch64-linux-gnu-gcc"

---

Pitfall Three: LTO Conflicts with Dynamic Linking

Symptom

macOS and Linux builds error out:

error: cannot prefer dynamic linking when performing LTO
note: only 'staticlib', 'bin', and 'cdylib' outputs are supported with LTO

Cause Analysis

prefer-dynamic (preferring dynamic linking) conflicts with lto = true (link-time optimization):

• Fat LTO (lto = true) requires static linking
• Dynamic linking produces dynamic library dependencies

Solution

Option 1: Use Thin LTO (recommended)

[profile.release]
strip = true
lto = "thin"  # changed from true to "thin"
opt-level = 3

Option 2: Fully disable LTO

[profile.release]
strip = true
# lto fully disabled (faster builds, but larger binaries)

Final Configuration

# .cargo/config.toml
[profile.release]
strip = true
lto = "thin"
opt-level = 3

---

Pitfall Four: apt Source Configuration for Ubuntu ARM64 Cross-Compilation

Symptom

apt installation fails during Linux ARM64 cross-compilation:

E: Failed to fetch https://security.ubuntu.com/ubuntu/dists/jammy/main/binary-arm64/Packages  404  Not Found
E: Failed to fetch https://security.ubuntu.com/ubuntu/dists/jammy-updates/main/binary-arm64/Packages  404  Not Found

Cause Analysis

Ubuntu 22.04’s default sources archive.ubuntu.com and security.ubuntu.com contain only x86_64 architecture packages. ARM64 architecture packages are hosted on ports.ubuntu.com.

Solution

1. Switch the apt sources to ports.ubuntu.com

# .github/workflows/release.yml
- name: Install ARM cross-compile dependencies
  if: matrix.target == 'aarch64-unknown-linux-gnu'
  run: |
    sudo dpkg --add-architecture arm64
    # Key: switch apt sources to ports.ubuntu.com (supports ARM64)
    sudo sed -i 's|http://archive.ubuntu.com/ubuntu/|http://ports.ubuntu.com/ubuntu-ports/|g' /etc/apt/sources.list
    sudo sed -i 's|http://security.ubuntu.com/ubuntu/|http://ports.ubuntu.com/ubuntu-ports/|g' /etc/apt/sources.list
    sudo apt-get update || true
    sudo apt-get install -y gcc-aarch64-linux-gnu g++-aarch64-linux-gnu
    sudo apt-get install -y libwebkit2gtk-4.1-dev:arm64 libappindicator3-dev:arm64 librsvg2-dev:arm64 patchelf || true

2. Configure the cross-compilation environment variables

- name: Setup ARM cross-compile env
  if: matrix.target == 'aarch64-unknown-linux-gnu'
  run: |
    echo "CARGO_TARGET_AARCH64_UNKNOWN_LINUX_GNU_LINKER=aarch64-linux-gnu-gcc" >> $GITHUB_ENV
    echo "CC_aarch64_unknown_linux_gnu=aarch64-linux-gnu-gcc" >> $GITHUB_ENV
    echo "CXX_aarch64_unknown_linux_gnu=aarch64-linux-gnu-g++" >> $GITHUB_ENV
    echo "PKG_CONFIG_SYSROOT_DIR=/usr/aarch64-linux-gnu" >> $GITHUB_ENV
    echo "PKG_CONFIG_PATH=/usr/lib/aarch64-linux-gnu/pkgconfig" >> $GITHUB_ENV
    echo "PKG_CONFIG_ALLOW_CROSS=1" >> $GITHUB_ENV

3. Cargo configuration

# .cargo/config.toml
[target.aarch64-unknown-linux-gnu]
linker = "aarch64-linux-gnu-gcc"

---

Full Configuration Reference

.github/workflows/release.yml

name: Release CI

on:
  push:
    tags:
      - "v*"

jobs:
  build-app:
    permissions:
      contents: write
    strategy:
      fail-fast: false
      matrix:
        include:
          - platform: "macos-latest"
            target: "aarch64-apple-darwin"
          - platform: "macos-latest"
            target: "x86_64-apple-darwin"
          - platform: "windows-latest"
            target: "x86_64-pc-windows-msvc"
          - platform: "windows-latest"
            target: "i686-pc-windows-msvc"
          - platform: "windows-latest"
            target: "aarch64-pc-windows-msvc"
          - platform: "ubuntu-22.04"
            target: "x86_64-unknown-linux-gnu"
          - platform: "ubuntu-22.04"
            target: "aarch64-unknown-linux-gnu"

    runs-on: ${{ matrix.platform }}
    steps:
      - uses: actions/checkout@v4

      - name: Setup node
        uses: actions/setup-node@v4
        with:
          node-version: 20

      - uses: pnpm/action-setup@v3
        with:
          version: latest

      - name: Install Rust
        uses: dtolnay/rust-toolchain@stable
        with:
          targets: ${{ matrix.target }}

      - name: Install dependencies (ubuntu only)
        if: matrix.platform == 'ubuntu-22.04'
        run: |
          sudo apt-get update
          sudo apt-get install -y libwebkit2gtk-4.1-dev libappindicator3-dev librsvg2-dev patchelf

      - name: Install ARM cross-compile dependencies
        if: matrix.target == 'aarch64-unknown-linux-gnu'
        run: |
          sudo dpkg --add-architecture arm64
          # Switch apt sources to ports.ubuntu.com
          sudo sed -i 's|http://archive.ubuntu.com/ubuntu/|http://ports.ubuntu.com/ubuntu-ports/|g' /etc/apt/sources.list
          sudo sed -i 's|http://security.ubuntu.com/ubuntu/|http://ports.ubuntu.com/ubuntu-ports/|g' /etc/apt/sources.list
          sudo apt-get update || true
          sudo apt-get install -y gcc-aarch64-linux-gnu g++-aarch64-linux-gnu
          sudo apt-get install -y libwebkit2gtk-4.1-dev:arm64 libappindicator3-dev:arm64 librsvg2-dev:arm64 patchelf || true

      - name: Rust cache
        uses: swatinem/rust-cache@v2
        with:
          workspaces: src-tauri/target
          key: ${{ matrix.target }}

      - name: Setup ARM cross-compile env
        if: matrix.target == 'aarch64-unknown-linux-gnu'
        run: |
          echo "CARGO_TARGET_AARCH64_UNKNOWN_LINUX_GNU_LINKER=aarch64-linux-gnu-gcc" >> $GITHUB_ENV
          echo "CC_aarch64_unknown_linux_gnu=aarch64-linux-gnu-gcc" >> $GITHUB_ENV
          echo "CXX_aarch64_unknown_linux_gnu=aarch64-linux-gnu-g++" >> $GITHUB_ENV
          echo "PKG_CONFIG_SYSROOT_DIR=/usr/aarch64-linux-gnu" >> $GITHUB_ENV
          echo "PKG_CONFIG_PATH=/usr/lib/aarch64-linux-gnu/pkgconfig" >> $GITHUB_ENV
          echo "PKG_CONFIG_ALLOW_CROSS=1" >> $GITHUB_ENV

      - name: Build the app
        uses: tauri-apps/tauri-action@v0
        env:
          CI: false
          GITHUB_TOKEN: ${{ secrets.GITHUB_TOKEN }}
          TAURI_SIGNING_PRIVATE_KEY: ${{ secrets.TAURI_PRIVATE_KEY }}
          TAURI_SIGNING_PRIVATE_KEY_PASSWORD: ${{ secrets.TAURI_KEY_PASSWORD }}
        with:
          tagName: ${{ github.ref_name }}
          releaseName: "ClipVault ${{ github.ref_name }}"
          releaseDraft: false
          prerelease: false
          args: --target ${{ matrix.target }}

.cargo/config.toml

# Windows targets need the /FORCE:MULTIPLE linker option
[target.x86_64-pc-windows-msvc]
rustflags = ["-C", "link-arg=/FORCE:MULTIPLE"]

[target.i686-pc-windows-msvc]
rustflags = ["-C", "link-arg=/FORCE:MULTIPLE"]

[target.aarch64-pc-windows-msvc]
rustflags = ["-C", "link-arg=/FORCE:MULTIPLE"]

# Linux ARM target configuration
[target.aarch64-unknown-linux-gnu]
linker = "aarch64-linux-gnu-gcc"

# macOS target configuration
[target.aarch64-apple-darwin]
linker = "clang"
rustflags = ["-C", "link-arg=-arch", "-C", "link-arg=arm64"]

[target.x86_64-apple-darwin]
linker = "clang"
rustflags = ["-C", "link-arg=-arch", "-C", "link-arg=x86_64"]

[profile.release]
strip = true
lto = "thin"
opt-level = 3

---

Build Matrix Summary

Platform	Architecture	Rust Target	Special Config
Windows	x86_64	x86_64-pc-windows-msvc	/FORCE:MULTIPLE
Windows	x86	i686-pc-windows-msvc	/FORCE:MULTIPLE
Windows	ARM64	aarch64-pc-windows-msvc	/FORCE:MULTIPLE
macOS	Intel	x86_64-apple-darwin	clang + arch flag
macOS	Apple Silicon	aarch64-apple-darwin	clang + arch flag
Linux	x86_64	x86_64-unknown-linux-gnu	default config
Linux	ARM64	aarch64-unknown-linux-gnu	ports.ubuntu.com + cross toolchain

---

Summary

The core points of Tauri cross-platform builds:

1. Code style: keep Biome/Prettier versions consistent and exclude the build output directory
2. Linker config: use Cargo’s conditional target configuration to avoid applying Windows-only options to other platforms
3. LTO strategy: use thin LTO to balance build speed and binary optimization
4. Cross-compilation: Ubuntu ARM64 needs to switch to the ports.ubuntu.com source

For the complete code, see the ClipVault GitHub repository.

---

This article is based on hands-on experience with Tauri 2.0 + GitHub Actions, and I hope it helps more developers avoid these pitfalls.
